Keyboard
61 standard size keys
Touch Response: Sensitivity 3 types, Off
Maximum Polyphony
64 notes (32 for certain tones)
Tones
Preset Tones: 800 ( 43 Indian & 57 SFX)
User Tones: 100
Other: Layer, split (configurable split point, lower point, chord point settings)
System Effects
Reverb: 24 types, Off
Chorus: 12 types, Tones
Delay: 15 types, Tones
DSP: 100 types (Can be applied to user tones using DSP editing.), DSP tones
Master Effects
Equalizer (10 presets)
External Input Effects
Center cancel (vocal cut) for input from the Audio In jack
Metronome
Beat: 0 (accented tone off), 1 to 16
Tempo: Tempo value: 20 to 255
Song Bank
Built-in Songs: 30
User-recorded Songs: 10
USB Memory Songs: Playback of standard MIDI files (SMF format 0/1),
CASIO MIDI files (CMF format) on a USB flash drive is supported.
USB Audio Playback
Playback of audio files on a USB flash drive is supported.
Supported File Formats: WAV format, 44.1 kHz 16 bit
Other Functions: Center Cancel (Vocal Cut)
Auto Accompaniment
Built-in Rhythms: 250 ( 39 Indian)
User Rhythms: 50
One Touch Presets 235
Music Presets
310 (With chord progressions)
Phrase Pads
Number of Pads: 4
User Phrases: 100 (4 phrases x 25 pads)
Editing Mode: Copy, delete, phrase editing
Mixer function
Affected Parts: Sound source parts, microphone input part
Parameters: Part on/off, volume, pan, reverb send, chorus send, delay send
Registration
Maximum 128 setups (8 setups x 16 banks), registration sequence
Tone Editing
Preset tone editing, DSP editing
Memory for storage of edited tones (up to 100)
Rhythm Editing
New rhythm creation, rhythm editing
Memory for storage of created/edited rhythms (up to 50)
MIDI Recorder
Real-time recording, playback
Keyboard Performance Recording: 10 songs, 17 tracks (1 system track, 16 solo tracks)
Memory Capacity: Approximately 40,000 notes (per song)
Editing Mode: Song editing, track editing, event editing, step input
Other Functions: Overdubbing, punch-in recording
Pedals
Sustain, sostenuto, soft, rhythm/song, expression
Controllers
Pitch bend wheel, SUSTAIN button, PORTAMENTO button
Other Functions
Transpose: 1 octaves (-12 to 0 to +12 semitones)
Octave Shift: Upper 1/Upper 2/Lower 1/Lower 2, 3 octaves
Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
Part coarse tune: For each keyboard part, 2 octaves (-24 to 0 to +24 semitones)
Part fine tune: For each keyboard part, 99 cents
Scales: 17 preset scales, scale fine tuning
Auto Harmonize: 12 types
Arpeggiator: 150 types
MIDI
16ch multi-timbre received, GM Level 1 standard
Inputs/Outputs
USB Flash Drive Port: Type A
USB Port: Type B
Pedal 1 Jack: Standard jack
Pedal 2, Expression Jack: Standard jack
Headphones Jack: Stereo standard jack
Audio Input Jack: Stereo mini jack/Input impedance 9 k?, Input sensitivity 200 mV
Power Supply
2-way
AC Adaptor: AD-A12150LW
Batteries: 6 D-size alkaline batteries
Battery Life: Approximately 10 hours continuous
Auto Power Off: Approximately 30 minutes after last operation; Can be disabled.
Speakers
10cm x 2 (Output: 6W + 6W)
Dimensions
W 94.8 x D 38.4 x H 11.6 cm
Weight
Approximately 6.9 kg (without batteries)
Included Accessories
Music stand, AC adaptor
